Intel Core Processors Industrial Fanless PC With DDR4 32GB RAM Windows 11 Linux
Industrial Fanless PC Description:
This fanless industrial mini computer is equipped with Intel 8th/9th/12th generation Core i7/i9 series processors and Intel UHD Graphics (depending on the CPU model). It can handle complex industrial automation programs or run high-precision design software with ease.
In addition, it also has 4 LAN Intel I211 Ethernet interfaces, supports network wake-up, automatic startup, PXE startup, and can customize POE function to meet the diverse needs of industrial networks. The mini-PCIe slot supports WIFI/3G/4G modules and SIM cards, and the LVD*1 interface facilitates the connection of special devices. Rich I/O interfaces, including DB9 COM interface, HDMI, USB3.0, USB2.0, etc., can easily connect various industrial equipment and achieve seamless docking.
Industrial Fanless PC Specification:
| CPU | Intel 8/9/12th Generation Core i7/i9 Series Processors |
| GPU | Intel UHD Graphics (depending on CPU model) |
| Memory | 1*DDR4 SODIMM RAM, Max Up To 32GB |
| Hard Disk | 1*M.2 NVMe 2280 SSD; 1*2.5'' HDD/SSD |
| Ethernet | 4*LAN Intel I211 Ethernet, Support Wake-on LAN, Auto Power On, PXE Boot; Support Customized POE Function |
| Extension | MINI-PCIE Slot*1, Support WIFI /3G/4G Module, SIM*1, LVDS*1 |
| Display | 1*HDMI1.4, 1*Built-in LVDS; Supports Synchronous Or Asynchronous Dual Screen Display |
| Operating System | Windows 10, Windows 11, Linux, etc. |
| I/O Interface | DB9 COM*6 (2*RS232/422/485, 4*RS232), HDMI*1, USB3.0*4, USB2.0*4, 16-bit Programmable GPIO*1, DC*1, AUD*1, Power Switch*1 |
| Power | 1*DC 9-36V Wide Voltage, Default 12V5A |
| Dimension | 205MM * 144MM * 64MM |
| Weight | About 1.45KG |
| Material | Aluminum Alloy Chassis |
| Installation | Wall Mount/ Desktop |
| Suitable Temperature | Operation Temperature: -20℃ to +70℃, Storage temperature: -30℃ to +70℃ |
Industrial Fanless PC Features:
It is also equipped with one DDR4 SODIMM memory, up to 32GB, one M.2 NVMe 2280 SSD and a 2.5" HDD/SSD hard disk, with fast read and write speed and large storage capacity, ensuring efficient and stable data processing.
This industrial pc with one HDMI1.4 interface and built-in a LVD interface support synchronous or asynchronous dual-screen display, which is convenient for use in scenarios such as industrial monitoring and multi-tasking operation, and can greatly improve work efficiency.
The fin heat dissipation design uses a carefully designed fin structure to greatly increase the heat dissipation area, efficiently conduct and dissipate the heat generated when the computer is running.
Without the need for a fan to rotate, it can ensure that the computer always maintains a stable low temperature state under long-term high-load operation, effectively avoiding performance degradation or hardware failure caused by overheating, and ensuring the continuity and stability of industrial production.
Whether it is industrial automation control, smart factory construction, or data collection and analysis, our industrial fanless mini computers can help you with excellent performance, rich functions and reliable quality.
|
|
